Method 401 UTV Beadlock Machined - Raw
OVERVIEW
The 401 Beadlock UTV wheel was developed for the serious off-road enthusiast and boasts an iconic 12 window design. It also features a push through center cap with debossed Method logos. The Schrader valve was strategically placed between wheel spokes for extra protection in harsh riding environments.
SPECIFICATIONS
- Part Number: MR40147047343B
- Wheel Diameter (IN): 14
- Wheel Width: 7.0
- Bolt Pattern: 4x136
- Offset (mm): 13
- Hub Bore (mm): 106.00
- Backside Spacing (in): 4.30
- Wheel Weight (LBS): 15.2
- Max Load (LBS): 1600
DETAILS
- Solid A356 aluminum with T6 heat treatment construction
- Iconic 12 window design with debossed METHOD logos
- Reinforced inner lip provides extreme strength and durability
- Protected Schrader valve place between wheel spokes
- Forged 6061 aluminum V.1 beadlock ring
- Grade 8 zinc-plated beadlock hardware kit included
- Push through center cap with embossed METHOD logo
- Super strong 1600 lbs. load rating
NOTE: Aftermarket wheels require spline drive lug nuts–OEM lug nuts are NOT compatible with these wheels.
